With the Holzmann BBSM50AUTO automatic drilling machine, you can drill the holes to insert your dowels and dowels to connect 2 panels.

Insert 4 dowels and 2 eccentric clamps + screws and a suitable threaded insert and you can create the ideal connection for your furniture. Either you do it manually or you do it with our automatic drill, saving time and precision!

General description of the Holzmann BBSM50AUTO – 400V automatic drill :

• Creation of the side hole and the hole for the eccentric assembly on one part as well as the holes for the connectors in the second part in 2 separate work steps.
• Base frame with door included

The Holzmann BBSM50AUTO automatic drill comes with :

• Drills/knives

Technical characteristics of the Holzmann BBSM50AUTO automatic drilling machine:

• Machine equipped with 3 motors (upper motor (550 W) / lower motor (250 W) and horizontal motor (550 W))
• Maximum drilling depth: 60 mm for the top 3 holes / 25 mm for the bottom hole / 40 mm for the 3 side holes
• Compressed air supply of 0.6-0.8 MPa required (connection to an external compressor)
• 400V three-phase connection
• Dimensions of the drilling table: 800 x 320 mm
• Total dimensions of the machine: 800 x 800 x 1410 mm
• Maximum thickness of parts to be drilled: 50 mm
• Sound level of the machine in operation: 85 dB(A)
• Weight: 146 kg
