The Holzprofi TSP2000E router-saw combination with 2300 mm trolley is perfect for demanding professionals and amateurs!

Built in heavy welded sheet metal. Aluminum slide trolley sliding on hardened high precision rails. 2500mm telescopic ruler with 2 stops on the trolley frame. Parallel guide with micrometric adjustment. 0-45 ° tilting saw blade. Fixed shaft router with suction in the table. Rectified cast iron tables. Very large capacities. Micrometric displacement routing housing and bar guides.

Attention: Delivered without saw blade, which gives you the choice between our different teeth depending on the work to be done. You can see the blades adaptable on this machine by clicking here: "carbide blade diameter 300 mm" or "carbide blade diameter 315 mm"

Important recommendation from Probois for many woodworking machines :

• Before starting up always check the inside of the machine, see if the belts are correctly put in place, tighten the bolts, grease the tables, etc ... because the different transportations cause vibrations.
• Always use an extension cord of 4² wire size
• The extension must not exceed 10 meters and must not be rolled up
• Provide an electric subscription pro 9kva mini subscription, a circuit breaker D 20A mini curve
• Have a standard electric meter with neutral and earth
• Always work with a chip vacuum cleaner for your health and for the guarantee of the machine
• Always grease cast iron tables with wood glide
• Always work with the protections in place
• Do not work with sharpened or blunt irons, this may damage the mechanism, the planer feed, break the belt.

Features of the Holzprofi TSP2000E router and saw combination :

• Shaft Diameter (mm): 30
• Working height (mm): 850
• Dimensions of the cast iron table (LxW) (mm): 1200x450
• Straight extension of sheet metal table: 800x860
• Sliding carriage length (mm): 2300x285
• Cutting length (mm): 2300
• Cutting width (mm): 140
• Trolley frame (LxW) (mm): 1200x610
• Max scoring diameter (mm): 120x20
• Max blade diameter (mm): 315x30
• Saw rotation (rpm): 4000
• Scoring rotation (rpm): 8000
• Blade tilt (°): 0-45 °
• Max cutting height at 90 ° (mm): 103
• Max cutting height at 45 ° (mm): 72
• Table top extension (LxW) (mm): 400X450
• Max tool diameter in the table (mm): 180
• Max diameter of the housing tool (mm): 200
• Spindle moulder diameter (mm): 30
• Shaft tilt (°): Fixed
• Shaft travel (mm): 125
• Rotary speed of router (rpm): 1500/3500/6000/8000
• Power 230V or 400V saw and router motors: 2.2kW / 3CV
• Scoring motor power: 0.75kw / 1hp
• Diameter of suction nozzles (mm): 120 + 120 + 120 + 60
• Weight (kg): 800
