Description of the metal band saw with variator Bernardo MBS 280 DG-V PRO :

• Torsion-free, strong spheroidal cast iron saw frame
• Bandsaw blade guiding via combined roll-jaw guide with carbide inserts
• Robust construction ensures smooth and vibration-free run
• Stepless lowering of saw frame via hydraulic cylinder
• Gear unit complete with hardened, polished worm shaft and bronze worm gear
• Robust cast iron vice with material fence, ideal for serial section
• Complete with stand and coolant device
• Automatic shut-down at cutting end
• Saw frame tilts left (-45°) and right (+60°) for double mitre cutting
• Includes a manometer for ideal blade tension

Technical characteristics of the Bernardo MBS280DG-V PRO metal band saw with variator:

• Cutting capacity 90 ° round / square: 225 mm / 180 x 180 mm
• Cutting capacity 90 ° flat: 245 x 150 mm
• Cutting capacity 45 ° G round / square: 120 mm / 120 x 120 mm
• Cutting capacity 45 ° G flat: 150 x 120 mm
• Cutting capacity 45 ° D round / square: 145 mm / 145 x 145 mm
• Cutting capacity 45 ° D flat: 145 x 190 mm
• Cutting capacity 60 ° D round / square: 90 mm / 90 x 90 mm
• Cutting capacity 60 ° D flat: 90 x 115 mm
• Working height: 990 mm
• Size of the band saw blade: 2480 x 27 x 0.9 mm
• Cutting speed: 20-90 m / min
• Engine pump watering S1 / 100%: 100W
• S1 / 100% motor: 1.5 kW
• Voltage: 400V
• Dimensions of the machine (W x D x H): 1500 x 1100 x 1470 mm
• Weight approx. : 250 kg

The Bernardo MBS280DG-V PRO Metal Band Saw comes with:

• Bandsaw blade
• Material fence
• Stand
• Manometer for blade tension
• Bandsaw blade guiding with carbide inserts
• Quick clamping vice
• Coolant device
• Hydraulic cylinder
• Motor protective switch
• Automatic shut-down
