Metal lathe Holzmann ED1000FBDIG - 400 V

7,375.00 € Tax included

Including €2.50 for ecotax

Reference: HED1000FBDIG-400V

The Holzmann ED1000FBDIG metal lathe is a powerful machine with a very quiet 1500 W motor suitable for use in machining centers with a frequency converter for infinitely variable speed with digital readout.

Quantity
Factory Shipping, delivery time 7-10 working days

  • Totally secure payment! Totally secure payment!
  • Be delivered where you want! Be delivered where you want!
  • 14 days to change your mind! 14 days to change your mind!

The Holzmann ED1000FBDIG metal lathe is ideally suited for use in machining centers, factories or schools!

This tour is versatile and allows a particularly robust mechanical turning!

The advantages of the Holzmann lathe:

  • Electromagnetic spindle brake at the foot, for maximum safety and maximum unproductive time via the stop of the spindle
  • Prismatic bench hardened by induction and precision ground
  • Gearbox with lubricated and oil bath ground gears for long service life
  • Quick change turret, halogen lamp and cooling system as standard.
  • Frequency inverter for continuously adjustable speed with digital readout.

The tour comes complete with: A fixed bezel, bezel to follow, counter tip, a lamp, a quick change turret, a water pump and a pedestal

Technical specifications Holzmann ED1000FBDIG metal lathe:

  • Engine power: 1.5 KW
  • Voltage: 400 V
  • Warehouse distance: 1000 mm
  • Height of tips: 181 mm
  • Max. machinable: 330 mm
  • Max. above the carriage: 198 mm
  • Max. under the bench: 450 mm
  • Bore of the spindle: 40 mm
  • Spindle speed: 70 - 2000 rpm
  • Morse taper of brooch: CM5
  • Morse taper of mobile doll: CM3
  • Spindle attachment: D1-4
  • Longitudinal feed: 0.053 - 1.29 rpm
  • Forward traverse: 0.013 - 0.31 rpm
  • Metric Thread Range (32): 0.4 - 7 mm
  • Thread range in inches (36): 4 - 60 TPI
  • Upper carriage stroke: 75 mm
  • Cross carriage travel: 130 mm
  • Trolley stroke: 760 mm
  • Sweeping fork stroke: 100 mm
  • Max capacity of the turret: 14 x 14 mm
  • Net weight: 600 kg
  • Package dimensions: 1870 x 740 x 1565 mm
