General description of the Bernardo Hobby 500 metal lathe with 2-axis digital display DT 40 - 230V :

• Gearbox for quick and easy speed change
• Prismatic bed induction hardened and ground
• Backlash guides
• Optimum price-performance ratio
• Very handy machine with lead screw for tapping
• Spindle mounted on 2 precision bearings
• Tailstock offset for machining tapered parts
• Safety switch with undervoltage coil
• Compact design

The Bernardo Hobby 500 metal lathe with 2-axis digital display DT 40 - 230V comes with :

• DT 40 2-axis digital indicator
• 3-jaw chuck 100 mm
• Interchangeable sprockets
• Fixed tailstocks
• 4 position turret
• Cross and top carriage
• Chuck guard

Technical characteristics of the Bernardo Hobby 500 metal lathe with 2-axis digital display DT 40 - 230V :

• Between centers: 500 mm
• Peak height: 110 mm
• Machinable diameter above bed: 220 mm
• Spindle passage: 20 mm
• Spindle taper: CM 3
• Rotational speed range: 140 - 1710 rpm, 6 speeds
• Longitudinal feeds: (4) 0.05 - 0.2 mm/rev
• Metric Threads: (11) 0.4 - 3mm
• Inch threads: (11) 8 - 28 TPI
• Tailstock quill stroke: 45 mm
• Tailstock quill cone: CM 2
• Continuous power S1 100%: 0.55 kW / 230 V
• Power S6 40%: 0.80 kW / 230 V
• Machine dimensions (W x D x H)*: 1150 x 480 x 420 mm
• Weight (approx.): 130 kg
• * without base
