The Holzprofi PCHO2600 oscillating edge sander is ideal for working solid and veneered wood edges!

This oscillating edge sander offers the possibility of working solid wood edges. It allows curvilinear sanding thanks to the cast iron table as well as very precise angle sanding thanks to the angle stop. The aggregate also tilts with a crank, which allows bevel sanding. The covers are easily removable, so sanding long pieces is done more quickly. Oscillation can be disconnected. Disengageable belt oscillation.

Technical data of the Holzprofi PCHO2600 oscillating edge sander:

• Dimensions work tables mm: 750x350
• Front extension: standard
• Travel of the table in height mm: 200
• Table tilt: 0-45°
• Device for sanding veneered edges with pad: yes
• Curvilinear sanding table: yes
• Dimensions of the belt bearing surface mm: 750x150
• Length x width of the strip mm: 2600x150
• Sanding belt speed m/s: 20
• Oscillating amplitude: 20
• Ø suction: 120
• Dimensions LxWxH mm: 1600 x 850 x 1350
• Oscillation motor power: 0.25kw, 0.34hp
• Motor power 400V-50Hz of 3000W or 4CV
• Rotation speed rpm: 2840
• Weight: 190kg

The Holzprofi PCHO2600 oscillating edge sander comes with:

• Sanding belt
• Band wobble
• Sanding device for veneered edges
• Complementary table
• Graphite strip
• miter guide
• sanding pad
• Suction hose

Important Probois recommendation for many woodworking machines:

• Before starting, always check the inside of your machine, see if the belts are fitted correctly, tighten the bolts, etc... because the various transports cause vibrations.
• Always use a 2.5² wire size extension cord
• The extension cord must not exceed 10 meters and must not be rolled up
• The use of drums, triplets or multi-plugs is PROHIBITED
• Have a standard electricity meter with neutral and earth
• Always work with a chip extractor for your health and for the guarantee of the machine
• Always work with guards in place
