Oscillating spindle sander Jean l'ébéniste PAO230

595.00 € Tax included

Including €2.50 for ecotax

Reference: HJPAO230

The Sander oscillating tree PAO230 of John the cabinetmaker, allows sanding curved parts as templates of routing or routing, as well as parts fretwork.

Quantity
Factory Shipping, delivery time 5-8 working days

  • Totally secure payment! Totally secure payment!
  • Be delivered where you want! Be delivered where you want!
  • 14 days to change your mind! 14 days to change your mind!

The inclination of the table allows to access impossible assignments to a fixed table Sander.

This cylindrical sleeve Sander is equipped with a large table support perfect when sanding.

It is stable with its weight of 30 kg and cast-iron table and allows access to more intensive work than the beginning of range models. It is a particularly popular machine of luthiers.

Small speed control combined with vertical movement to sand without risk of burning.

Table tilting cast-iron on double cradle with two locking knobs. 0 to 45 ° tilt adjustment Vernier.

Powerful and quiet asynchronous motor designed for continuous use.

Uniform wear of the abrasive cylinder by the oscillating motion. 3 diameters of standard cylinders mounted on threaded trees are easily interchangeable.

Nozzle for suction of dust to work clean and tidy and connectable to a vacuum Ø 50 or 100 mm.

Perforated inserts 6 game. They extend the table support to the more closely based on the choice of the cylinder. With several holes to improve aspiration. Three are equipped with a central hole of 30-60 and 85 mm for sanding with sleeve at 90 °. Three are equipped with oval holes 30 x 50-60 x 90 and 85 x 110 mm and allow sanding with the table tilted up to 45 °.

Technical characteristics :
Table size: 370 x 370
Table tilt: 0-45 °
Race of the tree: 24
Number of oscillations per minute: 60
Working height: max. 110
Shaft rotation speed: 1400 RPM
Out of aspiration (comes with 100 mm adapter): 50 mm
Dimensions of cylinders:
O 19.05 x 90
O 37.5 x 140
Ø 50 x 140
Number of inserts: 6
Weight: 30 kg
Motor 230 V / 50 Hz: 370 W

HJPAO230
1 Item
