General description of the Holzprofi Maker SAF1600M sliding table saw:

• The SAF1600M sliding table saw is powerful and solidly built, with a large recessed carriage for safe and precise work.
• The cast iron tables are precision machined to ensure a perfectly flat top surface and minimal resonance when cutting.
• With its large cutting capacity, its rear and side extensions, its carriage frame with telescopic ruler, its universal blade, its miter guide and its eccentric presser, its 2 stops and its ripping stop, it is an essential tool for your workshop!

Important recommendation from Probois for many woodworking machines:

• Before starting up, always check the inside of your machine, see if the belts are correctly fitted, tighten the bolts, etc... because the various transports cause vibrations.
• Always use an extension cord with a wire thickness of 2.5²
• The extension cord must not exceed 10 meters and must not be coiled
• The use of a reel, triplets or multi-socket is PROHIBITED
• Have a standard electric meter with neutral and earth
• Always work with a chip vacuum cleaner for your health and for the machine warranty
• Always work with the protections in place
• Do not work with dull or blunt tools, this can damage the internal mechanism.

Technical characteristics of the panel saw:

• Dimensions of the cast iron table (LxW): 795 x 350 mm
• Length of the sliding carriage: 1,600 mm
• Carriage frame (LxW): 420 x 600 mm
• 230/50Hz motor power: 3kW / 4CV
• Blade tilt: 0-45°
• Max cutting height at 90°: 100 mm
• Max cutting height at 45°: 75 mm
• Weight: 190 kg / 250 kg
• Packaging (L x W x H): 1,210 x 990 x 1,020 mm / 1,730 x 460 x 210 mm
• Dimensions of the table extensions (x2): 600 x 795 / 485 x 350 mm
• Rotation speed: 4,250 rpm
• Carriage width: 270 mm
• Cutting dimensions: 1,540 x 940 mm
• Telescopic ruler: 1,215 – 2,200 mm

Probois machinoutils informs you:

For a model with comparable skills to this Holzprofi Maker format saw or in case of rupture, see the Bernardo machine: TK315P

For exactly the same model as this Holzprofi Maker format saw but with a three-phase motor, see the Bernardo machine: FKS1600PRO
