Thicknesser and planer Bernardo PT250S with helical shaft

695.00 € Tax included

Including €2.80 for ecotax

Reference: BPT250S

Very compact, the PT250S Planer and thicknesser is easy to transport and is therefore an ideal machine for assembly work. This model is also equipped with a base.

Quantity
Delivery time 12-15 working days

  • Totally secure payment! Totally secure payment!
  • Be delivered where you want! Be delivered where you want!
  • 14 days to change your mind! 14 days to change your mind!

General description of the planer thicknesser Bernardo PT250S with helical shaft :

  • CE compliant shaft protection for maximum safety
  • IP 54 lockable on / off switch with undervoltage coil
  • Ideal for hobbyists and DIY enthusiasts
  • Quick and easy adjustment of the pass removal
  • Perfectly flat aluminum planing tables for a precise result
  • Combined suction hood can be used for either planing or planing
  • Stable guide tiltable from 90 ° to 45 °
  • Precision shaft with 2 HSS irons
  • Powerful motor for optimum planing
  • Compact and easy to transport, ideal for assembly operations

Technical characteristics of the thicknesser planer Bernardo PT250S with helical shaft :

Thicknesser

  • Cutting width: 255 mm
  • Table length: 925 mm
  • Shaft speed: 8500 rpm
  • Helical shaft
  • Shaft diameter: 50 mm
  • Guide: 620 x 125 mm
  • Tilt guide: 90 ° to 45 °
  • Maximum pass removal: 2 mm

Planer

  • Table length: 380 mm
  • Planer width: 250 mm
  • Planing height, min / max: 5 - 120 mm
  • Maximum pass removal: 2 mm
  • Feed speed: 7 m / min
  • ø suction nozzle: 75 mm

General

  • Continuous power S1 100%: 1.5 kW (2.0 hp)
  • Power S6 40%: 2.1 kW (2.8 hp)
  • Voltage: 230 V
  • Dimensions (L x W x H): 970 x 460 x 990 mm
  • Weight (approx.): 30 kg

Important recommendation from Probois for many woodworking machines:

Before starting, always check the inside of your machine, see if the belts are correctly installed, tighten the bolts, etc. because the various transports cause vibrations.

Always use an extension cord with a 2.5² wire thickness

The extension cord must not exceed 10 meters and must not be coiled

The use of a reel, triplets or multi-socket is PROHIBITED

Have a standard electric meter with neutral and earth

Always work with a chip vacuum cleaner for your health and for the machine warranty

Always grease the cast iron tables with wood slide

Always work with the guards in place

Do not work with blunt or dull irons, this can damage the mechanism, the advance of the planer, break the belt

BPT250S
2 Items

Data sheet

Delivery
Additional flat rate delivery
Types de machine
Largeur 250 à 260 mm, Arbre hélicoïdal
