General description of the Holzmann DHM630PRO planer :

• Motorized table regulation. 250W motor
• Independent feed motor: 550 W
• Welded one-piece structure, with very thick plates, and with cast iron table.
• 2 standard forward speeds. 4-16 m/min.
• Table prepared for as little friction as possible.
• Suction mouth: 150 mm
• Maximum room width: 630 mm
• Minimum length of the part: 280 mm
• Acoustic power dB(A): 100
• Sound pressure dB(A): 90

Important recommendation from Probois for many woodworking machines :

• Before starting, always check the inside of your machine, see if the belts are put on correctly, tighten the bolts, etc. because different transports cause vibrations.
• Always use an extension cord with a 2.5² wire size
• The extension cord must not exceed 10 meters and must not be coiled
• The use of drums, triplets or multi-grips is PROHIBITED.
• Provide an electric meter with special machine start-up fuses of at least 20A Curve D
• Have a standard electric meter with neutral and earth
• Always work with a chip vacuum cleaner for your health and for the warranty of the machine
• Always grease cast iron tables with wood slider
• Always work with protections in place
• Do not work with unsharpened or dull irons, this can damage the mechanism, the feed of the planer, break the belt

Technical characteristics of the Holzmann DHM630PRO planer :

• motor power s1: 7000 W
• Voltage: 400V / 3 / 50Hz
• feed speed: 4-16 m/min
• suction port: 150 mm
• total dimensions: 1060x1220x1150 mm
• table size: 1050 x 630 mm
• cutting depth: 8 mm
• thickness height: 300 mm
• shaft diameter: 117 mm
• shaft speed: 5500 min-1
• number of irons: 4
• sound power level: 100 dB (A)
• sound pressure level: 90 dB (A)
• gross weight: 720 kg
• net weight: 656 kg
• packaging width: 1150 mm
• packaging length: 1220 mm
• packaging height: 1300 mm

The Holzmann DHM630PRO planer comes with:

• 4 irons 630x30x3.0 mm

IMPORTANT FOR DELIVERY AND START-UP OF XS MACHINES!

XS machines are only shipped by 19 ton truck with tailgate. The delivery location must be planned so that this type of truck can approach and maneuver easily. If access is impossible by this type of truck, the machine must remain at the carrier's depot close to the customer who will then organize removal by its own means (trailer, van). If the carrier has the possibility to offer delivery by smaller truck, the additional costs will be the responsibility of the customer and must be paid before delivery. Getting started: The prices do not include assembly or electrical installation which must be done by a professional in order to avoid any damage to the motors and electrical circuits of the machine that the warranty cannot cover.
