Properties

• Both planing tables feature fine adjustment and are designed with slots to keep noise levels down
• Thicknessing table is guided on four threads to ensure accurate planing of boards, planks, etc.
• Integrated dust extractor guarantees optimal price-performance ratio
• Quick and easy adjustment of chip removal
• Dust hood (Ø 100 mm) can be used for both planing and thicknessing
• Cutterblock comes with HSS-knives
• Corrugated infeed roller ensures safe and consistent workpiece infeed
• Solid planer fence with prism guide can be tilted from 90° to 45°
• Serially equipped with knife gauge to allow accurate adjustment of knives
• Infeed can be switched off when planing

Technical specifications

Planer :

• Planing width : 305 mm
• Table length : 1080 mm
• Table height : 920 mm
• Shaft rotation speed : 6700 rpm
• Cutter knives : 2 pcs.
• Planer shaft diameter : 62 mm
• Planer fence : 640 x 125 mm
• Fence tiltable : 90° to 45°
• Max. cutting depth : 0.8 to 1 mm (hardwood) / 1 to 1.5 mm (softwood)
• Thicknesser :
• Table length : 500 mm
• Working width : 300 mm
• Working thickness, min./max. : 6 - 160 mm
• Max. cutting depth : 0.8 to 1 mm (hardwood) / 1 to 1.5 mm (softwood)
• Feed speed : 8,5 mm
• Dust extraction outlet : 100 mm / 75 mm
• Motor power output S1 100% : 1,8 KW (2,4 HP)
• Motor power input S6 40% : 2,5 KW (3,4 HP)
• Voltage : 400V
• Machine dimension (L x W x H) : 1140 x 820 x 1100 mm
• Weight approx. : 94 kg

Standard accessories

• Cutter knives in HSS-quality
• Knife gauge
• Integrated dust extractor
• Waste bag
• 2x Push handle
• Carriage

Bernardo specifies that this type of machine is intended for amateur use, the machining of the planing tables can therefore have variations in flatness of 0.3 to 0.5 tenths of a mm without this having any influence on the work, but we estimate that it is important to specify this and that is also why this machine is at a special price. Only machines with cast iron tables are perfectly flat.
