Technical characteristics of the Sliding mitre saw Holzprofi Maker BMS305 :

• Ø circular saw blade: 305 mm
• Dimensions of the carbide blade: ø305 x 32 x 30 mm - z60 alternating negative
• Blade rotation speed: 4,500 rpm
• Head tilt (right and left): 45 °
• Table rotation (right and left): 45 °
• Table indexation (left and right): 0/15/225/316/45
• Head translation: 305 mm
• Suction outlet with bag: 60 mm
• Motor power (230v / 50hz): 2000 W
• Belt drive
• Single laser (230V): line feeds
• Dimensions: 820 x 560 x 550 mm
• Weight: 25 kg

Cutting capacities :

• 0 ° table / 90 ° blade: 340 x 105mm
• 0 ° table / blade at - 45 °: 340 x 70mm
• table 0 ° / blade at + 45 °: 340 x 70mm
• table 0 ° / blade at + 45 °: 340 x 48mm
• 45 ° table / 90 ° blade: 235 x 105mm
• table -45 ° / blade at -45 °: 235 x 48mm
• table + 45 ° / blade at + 45 °: 235 x 40mm
