The Bernardo TK250RSN table saw is a massive and easily adjustable machine!

This machine is tilting from 90 ° to 45 ° and has a solid cast iron table with T-slots

The advantages of the TK250RSN:

• Supplied with its roller table
• Great ease of use with the roller table with aluminum stop
• Easy adjustment of cutting height and cutting angle by ergonomic rims
• Supplied with table extensions
• Including angle guide for angular cuts up to 45 °

This circular saw comes with: A carbide circular saw blade 250 x 3.0 x 30 mm / 40 teeth, a blade protector, a corner guide, a table extension , an aluminum stop and a sawing carriage

Technical specifications of the Bernardo TK250RSN table saw:

• Table dimensions: 635 x 430 mm
• Roller table: 400 x 254 mm
• Saw blade diameter max. : 250 x 30 mm
• Max. Cutting height 90 ° / 45 °: 80/60 mm
• Cutting width with the longitudinal guide: 750 mm
• Height of the table: 875 mm
• Table extension: 635 x 600 mm
• Speed ​​main saw blade: 4750 rpm
• Ø of the suction nozzle: 100 mm
• Output motor power S1 100%: 1.5 kW (2.0 hp)
• S6 engine power input 40%: 2.1 kW (2.85 HP)
• Voltage: 230 V
• Dimensions of the machine (W x D x H): 1500 x 1200 x 1050 mm
• Weight about: 96 kg

Important recommendation from Probois for many woodworking machines:

• Before starting, always check the inside of your machine, see if the belts are correctly placed, tighten the bolts, etc. because the various transports cause vibrations.
• Always use an extension cord with a 2.5² wire thickness
• The extension cord must not exceed 10 meters and must not be coiled
• The use of a reel, triplets or multi-socket is PROHIBITED
• Have a standard electric meter with neutral and earth
• Always work with a chip vacuum cleaner for your health and for the machine warranty
• Always work with the protections in place
• Do not work with blunt or dull tools, this can damage the internal mechanism.
