It has a polished granite table that provides a perfect glide of the wood and it is, due to its weight, extremely stable under load.

• The planing block is lifted using two worm screws and slides on 4 stainless steel columns.
• The rollers are driven by means of chains.
• The table is retractable for easy transport and the 2 irons are reversible without adjustment.
• This machine is equipped with a pass-taking feeler as well as a pre-adjustment of the planing height and has two drive rollers: 1 ribbed and 1 solid steel.

Technical characteristics of the Holzprofi RE330 planer:

• Planing width: 330 mm
• Planing height: 5 to 152 mm
• Planing table width: 330 mm
• Table dimensions: 330 x 240 mm
• Shaft rotation speed: 8,500 rpm
• Feed: 7 t / min
• Suction nozzle: Ø 65 or 100 mm
• Motor: 230V / 50Hz 1,5kW / 2cv
• Weight: 32 kg
• Open table dimensions: 711x503x480mm
• Package: 650x385x460mm / 35kg

Video of the machine assembly:

Video of the machine in use:
